Structure and Syntax for ANF V4


Introduction

Artwork's products have always relied on creating ANF V2 in order to interface with Ansys products. However the newer ANF V4 adds support for certain important entities.

In particular it supports:

  • polygons with arcs in the boundary
  • ports
  • components
