ASM 600 is a bidirectional translator between GDSII stream and Gerber. It is useful for generating photoplot artwork from CAD packages that read and write GDSII such a Tanner's LEDIT, Design Workshop 2000 and others.

ASM 600 includes a reverse translator (GBR2GDS) and also a GDSII Viewer and a Gerber viewer.





Application Notes

Run GBR2GDS in Batch Mode - this note describes how to run the gbr2gds translator in batch mode. Describes the required resource files and the command line syntax.



Run GDS2GBR in Batch Mode - this note describes how to run the gds2gbr translator in batch mode. Describes the required resource files and the command line syntax.



Run GBR2GDS in Batch Mode on UNIX - this note describes how to run the gbr2gds translator in batch mode. Describes the required resource files and the command line syntax.



Run GDS2GBR in Batch Mode on UNIX - this note describes how to run the gds2gbr translator in batch mode. Describes the required resource files and the command line syntax.



Flashing Circles in ASM600 UNIX - This note will explain how to flash polygons that look like circle into Gerber flashes.



Running ASM600 UNIX - This page describes the general procedure of running the ASM600 (GDSII to Gerber) on UNIX.



Running ASM600 Windows - This page describes the general procedure of running the ASM600 (GDSII to Gerber) on Windows.



Clean Gerber to GDSII Translations - Using Gerber Union to convert messy Gerber files to clean contor GDSII file.
